Cu
CU1332
Copper Sheet
- Thickness:
- 0.9 mm
- Purity:
- 99.98+%
- Description:
- Temper half hard OFHC C103.
Technical Data:
Maximum size 1m x 1m Typical analysis ppm: P<3, S<15, Zn<1, Cd<1, O<5, Hg<1, Bi<10, Pb<10, Se<10, Te<10,(Bi+Sn+Mn+Sb+As+Se+Te... Maximum size 1m x 1m Typical analysis ppm: P<3, S<15, Zn<1, Cd<1, O<5, Hg<1, Bi<10, Pb<10, Se<10, Te<10,(Bi+Sn+Mn+Sb+As+Se+Te total 40 max), O<20. Balance Cu 99.98+%.
Cut to size discs
Advent RM can supply various foils in disk format. Contact us for more information.
Citations
Formation mechanism and mechanical properties of compliant interconnects incorporating Cu nanowire arrays for heterogeneous integration
The conventional solder interconnects in heterogeneous integration face serious reliability issues resulting from thermally induced fatigue and premature brittle fracture. This study presents Cu nanowired compliant interconnects to solve these issues. Free-standing Cu nanowire (NW) arrays with...
